Description
The XW MPPT 60-150 can be used with 12, 24, 36, 48, and 60-volt DC battery systems
Two or three-stage charging process, with manual equalization to maximize system performance and maintain expected battery life
Maximum Power Point Tracking (MPPT) to deliver the maximum available power from a PV array to a battery bank
Configurable auxiliary power output
Two-line, 16-character liquid crystal display (LCD) and four buttons for configuration and system monitoring in stand-alone applications
Battery Temperature Sensor (BTS) to provide automatically temperature-compensated battery charging
The Charge Controller is able to communicate its settings and activity to other Xanbus-enabled devices
Additional Features
- Maximum Power Point Tracking (MPPT) delivers maximum available power from PV array to battery bank
- Integrated PV ground-fault protection
- Ultra-reliable, convection-cooled design does not require a cooling fan - large, aluminum, die-cast heat-sink allows full output current up to 45°C without thermal derating
- Selectable two or three-stage charging algorithms with manual equalization to maximize system performance and improve battery life
- Configurable auxiliary output
- Two-line, 16-character liquid crystal display (LCD) and four buttons for configuration and system monitoring
- Input over-voltage and under-voltage protection, output over-current protection, and backfeed (reverse current) protection (warning and fault messages appear on LCD when unit shuts down as a protective measure)
- Over-temperature protection and power derating when output power and ambient temperature are high
- Battery Temperature Sensor (BTS) included - automatically provides temperature compensated battery charging
- XanbusTM-enabled network communications protocol (developed by Xantrex)
- Communicates settings and activity to other XanbusTM-enabled devices, such as the XW Hybrid Inverter/Charger, the XW System Control Panel (XW SCP), XW Automatic Generator Start (XW AGS), and other XW Solar Charge Controllers.
- Five-year warranty
